Product Name
|
Model JDF5031TXFQC06/ZN6 Equipment Fire Truck
|
|
Overall Dimensions (mm)
|
5600×1890×2330
|
|
Gross Vehicle Weight (kg)
|
3200
|
|
Kerb Mass (kg)
|
2825
|
|
Front Passenger Seating
|
2+3
|
|
Chassis Model
|
ZN1038UCM6Y (Zhengzhou Nissan Pick‑up)
|
|
Number of Axles
|
2‑axle
|
|
Wheelbase (mm)
|
3400
|
|
Tire Specification
|
255/60R18
|
|
Fuel Type
|
Diesel
|
|
Emission Standard
|
GB18352.6‑2016 National‑VI
|
|
Engine
|
M9T‑60A, 120kW (163 HP)
|
|
Main Special Equipment
|
Equipped with various fire‑fighting equipment, Asia‑Pacific Mechatronic ABS system; optional cab according to chassis configuration, for rapid alarm response and front‑line rescue operation
|
