Isuzu Equipment Vehicle

Jiangte multi-purpose rescue vehicles are built on proven commercial truck chassis with a rational body layout and modular upper structure. Generator sets, control cabinets, lighting, winches, tail lifts and equipment racking can be fitted to match the mission.

Product Highlights

Product Specifications

Product Name	Model JDF5100XZBQ6 Equipment Vehicle
Overall Dimensions (mm)	6980×2360×3220
Gross Vehicle Weight (kg)	10000
Rated Payload (kg)	3655
Kerb Mass (kg)	6150
Front Passenger Seating	3 persons
Chassis Model	QL1110ANKAY (Qingling Isuzu)
Number of Axles	2‑axle
Wheelbase (mm)	3815,4175
Tire Specification	235/75R17.5 16PR, 8.25R20 14PR
Fuel Type	Diesel
Emission Standard	GB17691‑2018 National‑VI
Engine	Multiple Isuzu engine options: 4HK1‑TCG61, 4HK1‑TCG60, 4JZ1‑TCG62
Main Special Equipment	Equipment cabinets and storage racks; optional lifting tail‑gate, loading ramp and ETC; customizable exterior appearance and internal layout. Equipped with Asia‑Pacific Mechatronic ABS system, for transporting police and emergency rescue equipment
